Nordic Lights Work Light Kit, Mid-Sized Excavators

Nordic Lights Work Light Kit for Medium-Sized Excavators

Nordic Lights work light kit is specially designed for medium-sized excavators. Regardless of the model, Nordic Lights' LED work lights are inherently part of the Premium class. In this package, you have the option to choose between the cost-effective Basic set and the comprehensive Professional set. Both options are intended for professional use, ensuring the highest standards of functionality and durability. Each set includes professional-grade LED work lights from Nordic Lights.

Basic Set includes:

• 7x Nordic Scorpius Go 420 LED work light (wide beam pattern)

Professional Set includes:

• 4x Nordic Lights Scorpius Pro 415 PH LED work light
• 5x Nordic Lights Scorpius Pro 445 LED work light (wide beam pattern)

Technical specifications for the work lights:

Nordic Lights Scorpius Go 420 (Basic Set):

• Nominal operating voltage: 12-24V
• Actual input voltage: 9-16V, 18-32V
• Power: 28W
• Theoretical luminous flux: 2800lm
• Measured luminous flux: 1800lm
• Color temperature: 5000K
• Power consumption: 12V - 1.8A / 24V - 1.0A
• Built-in Deutsch DT-2 connector
• Shock resistance: 60G
• Vibration resistance: 8Grms 24-2000Hz
• Lens: Grilamid®
• Aluminum body
• Dimensions: 99 x 95 x 66mm, height with bracket 118mm
• Weight: 0.6kg
• IP rating: IP68, IP6K9K
• EMC: CISPR 25 Class 5, EN12895, ISO 13766, ISO 14982, ISO 7637-2
• Salt spray test: ISO 9227 240H
• Operating temperature: -40°C to +85°C (overheat protected)
• Warranty: 60 months

Nordic Lights Scorpius Pro 415 PH (Professional Set):

• Nominal operating voltage: 12-24V
• Actual input voltage: 9-16V, 18-32V
• Power: 28W
• Extremely wide beam pattern
• Theoretical luminous flux: 1950lm
• Measured luminous flux: 1500lm
• Color temperature: 5000K
• Power consumption: 12V - 2.4A / 24V - 1.2A
• Built-in Deutsch DT-2 connector
• Shock resistance: 60G
• Vibration resistance: 8Grms 24-2000Hz
• Lens: Glass
• Aluminum body
• Dimensions: 100 x 100 x 86mm, height with bracket 129mm
• Weight: 0.6kg
• IP rating: IP68, IP6K9K
• EMC: CISPR 25 Class 5, EN 14982-2, ISO 13766, EN 12895, ISO 11452-2, EN 13309, ISO 7637-2
• Salt spray test: ISO 9227 240H
• Operating temperature: -40°C to +85°C (overheat protected)
• Warranty: 60 months

Nordic Lights Scorpius Pro 445 (Professional Set):

• Nominal operating voltage: 12-24V
• Actual input voltage: 9-32V
• Power: 50W
• Theoretical luminous flux: 7000lm
• Measured luminous flux: 4400lm
• Color temperature: 5000K
• Power consumption: 12V - 4.2A / 24V - 2.1A
• Built-in Deutsch DT-2 connector
• Shock resistance: 60G
• Vibration resistance: 15.3Grms 24-2000Hz
• Lens: Grilamid®
• Aluminum body
• Dimensions: 108 x 108 x 87mm, height with bracket 137mm
• Weight: 1.1kg
• IP rating: IP68, IP6K9K, SAE J1455
• EMC: CISPR 25 Class 5, ISO 13766, ISO 14982, ISO 7637-2
• Salt spray test: ISO 9227 240H
• Operating temperature: -40°C to +85°C (overheat protected)
• Warranty: 60 months
